0.01-2000MHz 2Ghz Gain 32dB Broadband Low Noise Amplifier LNA RF Amplifier Module UHF VHF HF 12V DC with Shielded Shell
Description:
- the supply voltage: 12V DC (current 35MA) with a shielded shell
- gain: 32DB input and output impedance: 50 ohms
- the maximum output power: 10dBm (2VPP \ 50 ohm load)
- the input signal: <= – 22DBM (greater than -22 dBm input when the output signal has been distorted)
- bandwidth: 1MHz to 2GHz (different frequencies of the gain is different, please refer to the specific S21 curve indicators)
- the noise figure: 2dB (0.5GHz measurement)
- other: need different gain value, you can reduce the supply voltage, or custom.
Package Included:
- 1 x 0.01~2000MHz 2Ghz 32dB Low Noise Amplifier DC Broadband LNA RF Module UHF HF VHF
